Features
Ultra small size rack mount printer
Very silent printing thru direct thermal printing method
High speed (50mm/sec)
High resolution (8dots/mm, 192dots)
Serial(RS-232C or TTL) interface
Support text and graphic printing
Easier paper loading by CLAMSHELL design
Easier maintenance with self-diagnostics
Specification
| Item |
Specification |
| Printing |
Direct thermal line printing |
| Characters per line |
24cpl |
| Character size |
8x16dots, 9x24dots(korean characters) |
| Resolution |
203dpi, 8dots/mm |
| Print width |
1-inch (24mm, 192dots) |
| Printing speed |
50mm/sec (MAX) |
| Dimensions (WxDxH) |
53x44.2x24.4mm |
| Weight |
47g (including roll paper) |
| Interface |
Serial(RS-232C or TTL) |
| Paper supplied |
Thermal roll paper, label roll
(37mm wide, 20?) |
| Barcode supported |
PDF417, QR code, Data matrix(2-dimension),
Code128, Code39, I2/5, Code93, UPC, EAN(KAN, JAN), CODABAR |
| Receive buffer size |
1MB |
| Input Power |
5VDC, Standby 60mA and Max 2.5A |
| Operating temperature |
-10°C ~ 50°C |
| Storage temperature |
-10°C ~ 70°C |
| MCBF(Mean Cycle Between failure) |
Mechanical |
37,000,000 lines |
| Head |
Approximately 50 Km |
|
